  • D-Link NKJ-C6WHI1B21 Cat6 Utp Keystone Jack

    Jack Cat 6 Keystone UTP - White

    FEATURES :

    RJ45 8P 8C 180°C 50u Punch Down Jack
    Terminating 4 pairs, 22-26 AWG Cable
    Universal labels color coded for T568A and T568B wiring schemes
    Fitting high density keystone panel
    UL, ETL, RoHS certified

    SPECIFICATIONS :

    1.
    RJ45 Jack:
    Housing: PC, UL94V-0 with Option Color
    Contact Bracket: PC, UL94V-0 Transparent Colour
    2. RJ45 Jack Contact:
    Material: Phosphor Bronze with Nickel Plated
    Finish: 50 micro-inch Gold plated on Plug Contact area
    3. IDC:
    Housing: PC,UL94V-0
    Terminal: Phosphor Bronze with Tin plated
    4. IDC CAP: PC, UL94V-0
    5.
    PCB : FR4, UL 94V-0

    PERFORMANCE :

    T568A & T568B wiring sticker
    Insertion force: 20N max (IEC 60603-7-4)
    Retention strength : 7.7 kg between jack and plug
    Operation temperature : -10°C to 60̊C (ISO/IEC 11801, ANSI/TIA/EIA 568 C.2)
    Life ( Mating Cycles):
    Jack: 750 cycle min (ISO/IEC 11801, IEC 60603-7-4)
    IDC: suitable for 22-26 AWG stranded and solid wire, compatible with both 110 & Krone punch down tools
    The Cat6 transmission performance is in compliance with the ANSI/TIA/EIA 568 C.2 standard
